Datasheets

Two-page datasheets, engineered to the duty.

A 2-page PDF for every fan family and the main duties — the capability envelope, construction and materials, how each fan is specified, and the standards we build to. Pick one below and we send it to your inbox; every fan is still engineered to your operating point.

Request a datasheetGet a quote
Fan-family datasheets

By fan family

The seven centrifugal families we build, from the highest-efficiency aerofoil to the rugged radial.

AerofoilHighest-efficiency wing-profile backward blade — clean, filtered air only.ON ENQUIRY · 2-PAGE PDFBackward-CurvedThe everyday workhorse — moderate pressure, high efficiency, light dust.ON ENQUIRY · 2-PAGE PDFBackward-Curved PlateThe process-air workhorse — FD / PA / SA / combustion at medium-high pressure.ON ENQUIRY · 2-PAGE PDFBackward-Flat PlateHigh-flow specialist — large-diameter plate wheels for big volumes.ON ENQUIRY · 2-PAGE PDFRadial-TipSelf-cleaning straight tip — dust-laden draught at medium-high static.ON ENQUIRY · 2-PAGE PDFRadialThe rugged, highest-pressure family — the dirtiest, most abrasive gas.ON ENQUIRY · 2-PAGE PDFLarge-BackwardLarge-diameter, low-speed — high static where the fan must turn slowly.ON ENQUIRY · 2-PAGE PDF
Application datasheets

By duty

Each sheet shows a representative arrangement; the exact family and wheel are engineered to your point.

Induced Draft (ID)Hot, dust-laden flue-gas extraction and furnace-draught control.ON ENQUIRY · 2-PAGE PDFForced Draft (FD)Clean combustion air into boilers, fired heaters and burners.ON ENQUIRY · 2-PAGE PDFCombustion / Process AirMetered combustion and process air at controlled pressure.ON ENQUIRY · 2-PAGE PDFPrimary Air (PA)High-pressure mill and burner primary air.ON ENQUIRY · 2-PAGE PDFSecondary / Overfire Air (SA)Staged secondary and overfire air for combustion control.ON ENQUIRY · 2-PAGE PDFHot Gas / High-TempProcess gas above 300 °C with high-temperature construction.ON ENQUIRY · 2-PAGE PDFDust ExtractionSource-capture extraction — clean-side or dirty-side high-dust duty.ON ENQUIRY · 2-PAGE PDFPneumatic ConveyingHigh-pressure air for dilute-phase material transport.ON ENQUIRY · 2-PAGE PDFGeneral / Dilution VentilationBuilding and process dilution ventilation.ON ENQUIRY · 2-PAGE PDF
Request a datasheet

Tell us who you are — the PDF lands in your inbox.

Pick a datasheet (or click any card above) and give us your work email. We send the 2-page PDF and stay on hand for your duty point — every fan is engineered to your operating conditions.
