Applications

Primary Air fans — high static, stable across mill load.

A PA fan does more than an FD fan: it supplies the primary combustion air that entrains and conveys pulverised coal from the mill through the fuel pipes to the burner — so it runs at higher static, holds pressure steady as feeder rate swings across mill load, and shrugs off the light coal dust that rides through it. Cleaner than an ID fan, harder than an FD fan. We build PA fans across the full envelope below — up to 2,00,000 CMH, 2,000 mmWC and 400 HP.

2,00,000CMH max flow
2,000mmWC max static
350 °Chot primary air
400 HPdrive power
15,000+
fans built since 2011
200 HP
VFD test rig · IS 4894 / AMCA 210
99%
on-time delivery
3
working days to quote — always
UPSTREAM OF THE MILL · HIGH POSITIVE PRESSURE · CARRIES PULVERISED FUEL · INTO THE BURNER
What it does

A PA fan pushes harder than an FD fan — because it drives fuel, not just air.

A Primary Air fan sits upstream of the pulveriser: pushing primary air at high static through the mill to dry and transport the pulverised fuel, then carrying the fuel-air mixture down the pipe to the burner — holding pressure steady enough for stable firing as the mill feeder rate swings.

  • 01
    Push high

    Primary air at high static — the mill resistance, the fuel pipe and the burner together can demand 800–2,000 mmWC, well above a typical FD fan, because the fan must lift and carry pulverised fuel, not just deliver clean air.

  • 02
    Hold across mill load

    Primary-air flow tracks the feeder rate. As firing swings the mill load, the fan must hold pressure stable on the falling side of the curve — typically 5–15% right of the peak — so the fuel-air ratio and flame stay steady.

  • 03
    Ride the dust

    Cold-PA fans upstream of the mill handle clean air; hot-PA and combined-PA duty carries light coal dust off the mill. Not the heavy fly-ash load of an ID fan, but enough that leading-edge wear and balance matter on a high-tip-speed wheel.

INDUCED-DRAFT CENTRIFUGAL FAN Single-width single-inlet — scroll cut away to reveal the impeller inlet expansion joint MOTOR IE3 / VFD GAS IN GAS OUT n 1 2 3 4 5 6 7 8 9 10 1 Inlet cone (bell-mouth) 2 Backward-curved / radial-tipped impeller 3 Spiral volute casing 4 Replaceable AR wear plates (volute throat) 5 Shaft 6 Plummer-block bearings (L10 ≥ 40,000 h) 7 Shaft cooling disc (>400 °C duty) 8 Pedestal / base frame 9 Drive — motor + coupling 10 Outlet flange + duct take-off
Fig. 1PA centrifugal fan — single-width single-inlet, scroll cut away to reveal the backward-curved impeller. Numbered components keyed below the drawing.
Why it is hard

High static, mill-load swings and light coal dust decide whether a PA fan holds firing or fights it.

A PA fan is not just a high-pressure FD fan. The static is higher, so tip speed and wheel stress climb; the duty point moves with mill load, so a fan on the wrong side of its curve oscillates the fuel-air supply; and the light coal dust that rides through hot-PA service erodes a high-tip-speed wheel over time. Get the tip speed, the curve position and the wear margin right and the fan holds firing across the load range for 10+ years. Get them wrong and it stalls the mill or unbalances in 18–36 months.

01 — HIGH STATIC

Pressure to drive fuel, not just air

The mill, the fuel pipe and the burner together demand far more static than a clean-air FD duty — up to 2,000 mmWC. That pressure comes from tip speed, which drives up wheel stress and blade-root fatigue on a continuously-loaded fan.

How we engineer it out

Backward-curved / backward-inclined wheels engineered for the tip speed the static demands, with blade-root stress checked against continuous duty and the whole wheel balanced to ISO 21940 G6.3 (G2.5 on application) so the high-speed rotor runs true.

02 — MILL-LOAD STABILITY

Curve instability as firing swings

Primary-air flow tracks the feeder rate, so the duty point moves continuously with mill load. Sized onto the flat or rising part of its curve, a PA fan stalls under back-pressure swings — oscillating the fuel-air supply and destabilising the flame.

How we engineer it out

We engineer the duty point onto the falling, stable portion of the pressure–flow curve — typically 5–15% right of the peak — so the fan is inherently stable across the mill-load range, then prove the curve on the rig.

03 — COAL-DUST WEAR

Light coal dust on a high-tip-speed wheel

Hot-PA and combined-PA fans carry light pulverised-coal dust off the mill. It is not the heavy fly-ash load of an ID fan, but on a high-tip-speed PA wheel even a light abrasive load erodes leading edges and, unevenly, throws the rotor out of balance.

How we engineer it out

Hard-faced (chrome-carbide) leading edges and impeller geometry chosen to shed dust from the blade root, with bolted-in AR400 wear plates and access doors where the coal-dust loading warrants it — replaceable in place, not welded in.

How we design for it

Every choice is documented on the GA drawing you sign off — before we cut metal.

We don't sell a catalogue near-fit. The fan is engineered to your primary-air temperature, static rise, mill-load turndown and coal-dust condition — hot or cold PA.

  • Impeller geometry & tip speed — Backward-curved or backward-inclined for high static at good efficiency on PA duty; tip speed and blade-root stress engineered to the pressure rise the mill and burner demand, not a catalogue speed.
  • Wear protection — hot / combined PA — Cold-PA (upstream of the APH and mill) is clean air, no wear scope. Hot-PA and combined-PA carry light coal dust: chrome-carbide leading edges and bolted-in AR400 wear plates sized to the loading, replaceable through access doors.
  • Control — VFD as default — Primary-air demand tracks mill load, so turndown is real. VFD speed control avoids the throttling loss of an inlet damper at part-load and holds the fuel-air ratio steady as firing swings — our default; inlet vane dampers remain available for legacy retrofit.
  • Hot-PA thermal handling — Downstream of an air pre-heater the primary air may run 200–350 °C — casing upgraded to IS 2062 or 16Mo3, shaft sized for thermal growth, bearings selected for sustained 80–100 °C housing temperature, expansion joints on the hot connections.
Engineered to your duty point

We size the fan onto the stable side of its curve — then prove it on the rig.

No catalogue fan forced onto your spec. Your operating point is engineered onto the falling, stable portion of the selected wheel — 5–15% right of the peak, where a PA fan holds pressure across mill load — and verified on the 200 HP VFD test rig before dispatch.

avoid: unstable 0 40,000 80,000 1,20,000 1,60,000 2,00,000 VOLUME FLOW RATE  [ CMH ] 0 500 1000 1500 2000 STATIC PRESSURE  [ mmWC ] 0 25 50 75 100 STATIC EFFICIENCY  [ % ] Fan static pressure System resistance Static efficiency BEP 82% DUTY POINT 1,20,000 CMH · 450 mmWC Fan static pressure System resistance Static efficiency
Fig. 2Representative PA-fan characteristic — fan static pressure, system resistance and static efficiency vs. flow, with the duty point engineered onto the falling, stable region right of the peak. Illustrative; every fan is sized to its own duty.
Capability envelope — PA service

What we can supply, and where it stretches on application.

ParameterStandardOn application
Volume flowup to 2,00,000 CMHhigher on enquiry
Static pressureup to 2,000 mmWChigher on enquiry
Primary-air temperatureup to 350 °C (hot PA, post-APH)higher on application with special metallurgy
Inlet dust loadingcold PA clean; hot / combined PA carries light coal dusthigher with enhanced wear protection
Static efficiencyhigh (backward-bladed) on PA duty — figures shared on enquiryhigher on high-efficiency builds
Drive powerup to 400 HPhigher with custom motor sourcing
Speed600–1,800 RPM typicalper duty + sound limits
Balance qualityISO 21940 G6.3G2.5 / G1.0 on application

The envelope above covers the great majority of industrial PA-fan duty. For duty beyond it, we engineer to spec and quote on enquiry. Cold-PA fans upstream of the mill and air pre-heater handle clean air with no wear scope; hot-PA and combined-PA fans carry light pulverised-coal dust off the mill (light coal-dust load), where leading-edge hard-facing and bolted-in wear plates apply. Hot-PA inlet temperature runs 200–350 °C downstream of an APH and calls for upgraded casing metallurgy and shaft thermal scope. Bearing life is a design target of L10h ≥ 40,000 h continuous, with longer L10 on application.

How a Jitamitra PA fan is specified

Specified, not picked from a shelf.

The same engineering language carries from your enquiry to the GA drawing to the nameplate — expressed in the standard AMCA conventions.

Specification fieldOptions
Arrangement (AMCA 99)Arr. 1 (overhung, fan bearings) / Arr. 4 (direct, motor on base) / Arr. 8 (overhung on common base) / Arr. 9 (overhung, motor side) / Arr. 10 (overhung, motor inside base) — selected by drive, access and temperature.
Width / inletSWSI (single width, single inlet) default for PA duty; DWDI (double width, double inlet) for high flow at moderate pressure on large mill lines.
Wheel typeBackward-curved or backward-inclined (default, high static at good efficiency on PA duty); radial-tipped backward-curved where the coal-dust wear condition is heavier.
Class (by pressure / outlet velocity)Class II / III typical for PA (higher static than FD) selected from the duty point on the pressure-vs-outlet-velocity limits; higher class = heavier construction for higher pressure and tip speed.
Materials of constructionMild steel + epoxy coating (standard cold PA) / chrome-carbide-faced leading edges and AR400 bolted wear plates for hot / combined PA coal dust / IS 2062 or 16Mo3 casing for hot-PA temperature / stainless for humid coastal inlet air.
DriveDirect-coupled / V-belt / VFD (default for mill-load control). Drive up to 400 HP across the envelope; speed typically 600–1,800 RPM.
Discharge & rotation (AMCA orientation)Rotation CW or CCW (viewed from drive side) with discharge angle per AMCA — e.g. TH/BH/UB/DB — set to match your fuel-pipe take-off and installed footprint.
Accessories & high-static scopeInlet vane damper or VFD control; bolted-in AR400 wear plates and access doors on coal-dust duty; expansion joints and thermal scope for hot-PA service; shaft cooling disc where hot-PA temperature requires; inlet and outlet silencers with acoustic-lagged casing; drain and inspection doors.
The proof, not the promise

We test before we ship — and you're welcome to witness it.

Every job's performance is verified at our works on the 200 HP VFD test rig, to the AMCA 210 / ISO 5801 method, before dispatch.

  • Customer-witnessed FAT on request — at no extra cost
  • Rotors balanced to ISO 21940 G6.3 as standard (G2.5 / G1.0 on application) before they leave the floor
  • Full NDT in-house — DP, MPI, UT, RT — to what the duty demands
30+ INDUSTRIES · 45 APPLICATION / DUTY TYPES
Where our PA fans run

Engineered for the fan that carries the fuel.

Power Generation

Pulverised-coal boiler primary air — cold-PA, hot-PA and combined-PA duty feeding the mills and burners.

Cement

Coal-mill primary air for kiln main-burner and calciner firing systems.

Iron & Steel

Pulverised-coal injection (PCI) and coal-mill primary air on furnace firing lines.

Sugar & Distilleries

Bagasse and biomass co-firing primary air on captive boilers.

Chemicals & Petrochem

Solid-fuel process-boiler primary air for coal- and biomass-fired steam.

Pulp & Paper

Recovery- and power-boiler primary air on solid-fuel firing.

Waste-to-Energy

Primary air for RDF- and biomass-fired combustion lines.

Your process

45 application/duty types engineered. Tell us yours.

Standards & conformity

Stated precisely — because procurement checks.

What our marks mean, in the words that survive an audit.

Performance

Tested to the AMCA 210 / ISO 5801 method, in-house on our 200 HP VFD rig. Tested-to-method — not AMCA-certified.

Quality system

ISO 9001:2015 — third-party certified. Our only third-party certification.

CE conformity

Self-declared per 2006/42/EC + 2014/35/EU (Module A). A self-declaration, not a notified-body certificate.

ATEX conformity

Self-declared, Zone 2/22, Category 3, per 2014/34/EU, where the area classification calls for it.

Oil & gas duty

Designed and built to API 673 as project-specific scope.

Welding

ASME Sec IX qualified welders + WPS for every joint.

Balance

ISO 21940 — G6.3 minimum, G2.5 / G1.0 on application.

Vibration

ISO 20816 evaluation; ISO 14694 for fan-specific limits.

Lead time & process

From enquiry to a tested fan on your dock.

StageStandard dutyAPI-673 / engineered
Offer / quotation3 working days — always7–10 working days
GA drawing for approval2–3 weeks from PO3–4 weeks from PO
Manufacture + balance + paint6–10 weeks10–14 weeks
Performance test + witnessed FAT~1 week1–2 weeks
Order-to-dispatch (total)9–14 weeks14–20 weeks

Shutdown-driven replacements: we have shipped fans within 6 weeks of a clean PO. Tell us your shutdown window and we commit to a dated plan.

Questions engineers ask

The eight we hear most before a PO.

What is the difference between a Primary Air fan and a Forced Draft fan?
Both push air on the clean side of combustion, but a PA fan does more. An FD fan delivers combustion air to the windbox at moderate static. A PA fan drives primary air at higher static through the pulveriser to dry and transport the fuel, then carries the fuel-air mixture down the pipe to the burner. That means higher pressure, higher tip speed, and a curve that must stay stable as the mill feeder rate swings. Cold-PA fans handle clean air; hot-PA and combined-PA fans carry light coal dust off the mill, so unlike an FD fan they often need leading-edge wear protection. We engineer the PA fan to the mill and burner resistance, not to a generic FD rating.
What is the difference between cold PA and hot PA, and does it change the fan?
Yes, it changes the whole build. A cold-PA fan sits upstream of the air pre-heater and mill and handles clean ambient air at high static, so the focus is tip speed, curve stability and efficiency. A hot-PA fan sits downstream of the APH where the primary air runs 200 to 350 °C and, on combined-PA arrangements, carries light coal dust off the mill, so it also gets upgraded casing metallurgy, shaft thermal sizing and leading-edge wear protection. Tell us where the fan sits in the mill circuit and we build to that position rather than a single default.
How do you keep a PA fan stable as mill load swings?
Primary-air flow tracks the feeder rate, so the duty point moves continuously with mill load, and a fan sized onto the flat or rising part of its curve can stall under back-pressure swings and oscillate the fuel-air supply. We engineer the duty point onto the falling portion of the pressure-flow curve, typically 5 to 15 percent to the right of the peak, so the fan is inherently stable across the mill-load range. We then verify the curve on the 200 HP VFD test rig before dispatch.
PA fans run at high static. How do you manage the tip speed and wheel stress?
The static a PA fan makes comes from tip speed, and higher tip speed drives up wheel stress and blade-root fatigue on a fan that runs continuously. We engineer the wheel to the pressure the mill and burner actually demand, check blade-root stress against continuous duty rather than a catalogue rating, and balance the rotor to ISO 21940 G6.3 as standard, with G2.5 or G1.0 on application, so the high-speed wheel runs true. On hot-PA and combined-PA duty we also hard-face the leading edges so light coal dust does not erode the wheel unevenly and unbalance it.
Our PA fan carries pulverised coal dust. What wear protection do you fit?
Hot-PA and combined-PA fans carry light pulverised-coal dust off the mill, a far lighter load than the fly-ash on an ID fan but still enough to erode a high-tip-speed wheel. We fit chrome-carbide hard-facing on the blade leading edges and choose impeller geometry that sheds dust from the blade root, and where the loading warrants it we bolt in AR400 wear plates at the volute throat and outlet with access doors for in-place replacement. Cold-PA fans on clean air upstream of the mill need no wear scope at all. We size the wear package to your stated coal-dust condition.
Should I specify VFD or an inlet vane damper for control?
VFD is our default. Primary-air demand tracks mill load, so a PA fan turns down meaningfully across the firing range, and VFD speed control is more efficient than an inlet vane damper across the operating range because it avoids the throttling loss at part-load. Speed control also holds the fuel-air ratio steady as firing swings, which matters for stable flame. Inlet vane dampers remain available for legacy retrofit where the existing motor and starter cannot accommodate a drive. We quote whichever your installation calls for.
What is the lead time for a standard PA fan?
A standard engineered PA fan runs roughly 9 to 14 weeks order-to-dispatch: offer in 3 to 5 working days, GA drawing 2 to 3 weeks from PO, manufacture, balance and paint 6 to 10 weeks, and performance test plus FAT 1 week. A hot-PA or combined-PA build with wear protection and thermal scope sits at the longer end. API 673 refinery-adjacent duty runs longer, roughly 13 to 19 weeks, with a 7 to 10 working-day offer turnaround.
Do you build PA fans to API 673, CE and ATEX requirements, and are your fans certified?
Yes to the build; let us be precise about the claims. We design and build to API 673 for oil-and-gas and fired-heater-adjacent service as project-specific scope (allow 7 to 10 working days for the offer). CE is self-declared per 2006/42/EC and 2014/35/EU, and ATEX Zone 2/22 is self-declared per 2014/34/EU, Category 3, where the area classification calls for it. Those are self-declarations of conformity, not third-party certifications. Performance is tested in-house to the AMCA 210 / ISO 5801 method on our 200 HP VFD test rig; that is testing to the AMCA method, not an AMCA certification, and we are not an AMCA member. Our only third-party certification is ISO 9001:2015. Balance is to ISO 21940 G6.3 as standard, and bearing life is a design target of L10h at least 40,000 hours continuous.
Across the range

Where primary air fans fit — the fans that run them, related duties, and the industries served.

The same engineering, viewed three ways — by fan family, by duty, and by industry. Follow the cross-references.

Take it further

Specs an engineer can use — not a brochure.

Engineer to engineer

Send us the duty point.
We'll quote in 3 working days — always.

No model numbers needed. Give us the operating conditions — flow, static, gas temperature, composition, particulate, and any tender standard — and our application engineers size the fan and quote it. Attach a spec or GA if you have one.
