Fans we have built for edible oil and solvent extraction

Solvent-zone extraction and desolventiser air with the classification the plant has declared. Every card is a real dispatched build, with its verified duty point.

Get a quote

Read what we engineer for edible oil and solvent extraction · See the whole gallery

Flow on this page runs from 340 to 69,700 CMH, against static pressure to 650 mmWC, at gas temperatures to 80 °C. The wheels here are backward-curved plate, backward-curved and backward-flat plate. How we choose for this duty: AMCA Type A, B and C spark resistance.

Backward-curved fan built by Jitamitra for combustion and process air, 1,337 CMH at 100 mmWC and 80 °C — 1,337CMH/100mmWC/80°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-curved plate fan built by Jitamitra for combustion and process air, 7,500 CMH at 270 mmWC and 65 °C — 7,500CMH/270mmWC/65°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-curved fan built by Jitamitra for pneumatic conveying, 400 CMH at 300 mmWC and 40 °C — 400CMH/300mmWC/40°C
Pneumatic conveying (dilute) · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for spray and fluid-bed drying, 23,800 CMH at 635 mmWC and 40 °C — 23,800CMH/635mmWC/40°C
Drying (spray / fluid-bed / flash) · Edible Oil & Solvent Extraction

Backward-curved fan built by Jitamitra for combustion and process air, 3,740 CMH at 100 mmWC and 80 °C — 3,740CMH/100mmWC/80°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-curved fan built by Jitamitra for combustion and process air, 1,700 CMH at 50 mmWC and 80 °C — 1,700CMH/50mmWC/80°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for combustion and process air, 1,331 CMH at 100 mmWC and 80 °C — 1,331CMH/100mmWC/80°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for combustion and process air in edible oil and solvent extraction — Duty on request
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for combustion and process air, 1,309 CMH at 100 mmWC and 80 °C — 1,309CMH/100mmWC/80°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-curved fan built by Jitamitra for combustion and process air, 2,720 CMH at 100 mmWC and 80 °C — 2,720CMH/100mmWC/80°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-curved plate fan built by Jitamitra for combustion and process air, 425 CMH at 100 mmWC and 75 °C — 425CMH/100mmWC/75°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-curved plate fan built by Jitamitra for dust extraction, 37,400 CMH at 550 mmWC and 35 °C — 37,400CMH/550mmWC/35°C
Dust extraction (dirty side) · Edible Oil & Solvent Extraction

Backward-curved plate fan built by Jitamitra for dust extraction, 340 CMH at 100 mmWC and 60 °C — 340CMH/100mmWC/60°C
Dust extraction (dirty side) · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for combustion and process air, 2,295 CMH at 100 mmWC and 60 °C — 2,295CMH/100mmWC/60°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for spray and fluid-bed drying, 7,820 CMH at 280 mmWC and 20 °C — 7,820CMH/280mmWC/20°C
Drying (spray / fluid-bed / flash) · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for spray and fluid-bed drying, 7,140 CMH at 255 mmWC and 20 °C — 7,140CMH/255mmWC/20°C
Drying (spray / fluid-bed / flash) · Edible Oil & Solvent Extraction

Backward-curved plate fan built by Jitamitra for dust extraction, 28,900 CMH at 550 mmWC and 20 °C — 28,900CMH/550mmWC/20°C
Dust extraction (dirty side) · Edible Oil & Solvent Extraction

Backward-curved plate fan built by Jitamitra for combustion and process air, 527 CMH at 100 mmWC and 80 °C — 527CMH/100mmWC/80°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-curved plate fan built by Jitamitra for combustion and process air, 10,200 CMH at 255 mmWC and 20 °C — 10,200CMH/255mmWC/20°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for ATEX paint-booth exhaust, 20,400 CMH at 305 mmWC and 80 °C — 20,400CMH/305mmWC/80°C
ATEX / paint-booth exhaust · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for combustion and process air, 69,700 CMH at 650 mmWC and 20 °C — 69,700CMH/650mmWC/20°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for combustion and process air, 15,300 CMH at 305 mmWC and 80 °C — 15,300CMH/305mmWC/80°C
Combustion / process air blower · Edible Oil & Solvent Extraction

Backward-flat plate fan built by Jitamitra for combustion and process air, 800 CMH at 475 mmWC and 40 °C — 800CMH/475mmWC/40°C
Combustion / process air blower · Chemicals & Petrochemicals

Duty points are the customer's design conditions, verified from our manufacturing records (GA drawings / M.O. sheets). Customer names and identifying marks are withheld.

Seen a fan like yours? Tell us your duty point.

Give us the flow, static pressure, gas and temperature — our engineers size it and quote in 3 to 5 working days.^*
